Deye Three Phase String Inverter SUN-4/5/6/7/8/10/12K-G05
Remotely shutdown function
Thanks to the smart monitoring platform, Deye full series inverter products support remotely shutdown immediately when accident occurs.Setting parameters and FW update remotely, which makes PV plant O&M easier.
● 2 MPP tracker, Max. efficiency up to 98.3%
● Zero export application, VSG application
● String intelligent monitoring (optional)
● Wide output voltage range
● Anti-PID function (Optional)
Smart Monitoring Platform
| Model SUN-4K-G05-P SUN-5K-G05-P SUN-6K-G05-P SUN-7K-G05-P SUN-8K-G05-P SUN-10K-G05-P SUN-12K-G05-P | ||||||||||
| Max. DC Input Power (kW) | 5.2 | 6.5 | 7.8 | 9.1 | 10.4 | 13 | 15.6 | |||
| Max. DC Input Voltage (V) | 1000 | |||||||||
| Start-up DC Input Voltage (V) | 140 | 250 | ||||||||
| MPPT Operating Range (V) | 120~850 | 200~850 | ||||||||
| Max. DC Input Current (A) | 20+20 | |||||||||
| Max. Short Circuit Current (A) | 30+30 | |||||||||
| No.of MPP Trackers | 2 | |||||||||
| No.of Strings per MPP Tracker | 1 | |||||||||
| Output Side | ||||||||||
| Rated Output Power (kW) 4 | 5 | 6 | 7 | 8 | 10 | 12 | ||||
| Max. Active Power (kW) 4.4 | 5.5 | 6.6 | 7.7 | 8.8 | 11 | 13.2 | ||||
| Nominal Output Voltage / Range (V) 3L/N/PE 220/380V, 230/400V | ||||||||||
| Rated Grid Frequency (Hz) | 50 / 60 (Optional) | |||||||||
| Operating Phase | Three phase | |||||||||
| Rated AC Grid Output Current (A) 6. 1/5.8 | 7.6/7.2 | 9. 1/8.7 | 10.6/10. 1 | 12. 1/11.6 | 15.2/14.5 | 18.2/17.4 | ||||
| Max. AC Output Current (A) 6.7/6.4 | 8.3/8 | 10/9.6 | 11.7/11. 1 | 13.3/12.8 | 16.7/15.9 | 20/19. 1 | ||||
| Output Power Factor | 0.8 leading to 0.8 lagging | |||||||||
| Grid Current THD | <3% | |||||||||
| DC Injection Current (mA) | <0.5% | |||||||||
| Grid Frequency Range | 47~52 or 57~62 (Optional) | |||||||||
| Efficiency | ||||||||||
| Max. Efficiency | 98.3% | |||||||||
| Euro Efficiency | 97.5% | |||||||||
| MPPT EfficiencyDC Reverse-Polarity Protection | >99%Yes | |||||||||
| AC Short Circuit Protection | Yes | |||||||||
| AC Output Overcurrent Protection | Yes | |||||||||
| Output Overvoltage Protection | Yes | |||||||||
| Insulation Resistance Protection | Yes | |||||||||
| Ground Fault Monitoring | Yes | |||||||||
| Anti-islanding Protection | Yes | |||||||||
| Temperature Protection | Yes | |||||||||
| Integrated DC Switch | Yes | |||||||||
| Remote software upload | Yes | |||||||||
| Remote change of operating parameters | Yes | |||||||||
| Surge protection | DC Type II / AC Type II | |||||||||
| General Data | ||||||||||
| Size (mm) | 330W×457H×185D | 330×457×205 | ||||||||
| Weight (kg) | 10 | 11 | ||||||||
| Topology | Transformerless | |||||||||
| Internal Consumption | <1W (Night) | |||||||||
| Running Temperature | -25~65C, >45C derating | |||||||||
| Ingress Protection | IP65 | |||||||||
| Noise Emission (Typical) | <30 dB | |||||||||
| Cooling Concept | Natural cooling | |||||||||
| Max. Operating Altitude Without Derating | 2000m | |||||||||
| Warranty | 5 years | |||||||||
| Grid Connection Standard | VDE4105, IEC61727/62116, VDE0126, AS4777.2, CEI 0 21, EN50549-1, G98, G99, C10-11, UNE217002, NBR16149/NBR16150 | |||||||||
| Operating Surroundings Humidity | 0- 100% | |||||||||
| Safety EMC / Standard | IEC/EN 61000-6- 1/2/3/4, IEC/EN 62109- 1, IEC/EN 62109-2 | |||||||||
| Features | ||||||||||
| DC Connection | MC-4 mateable | |||||||||
| AC Connection | IP65 rated plug | |||||||||
| Display | LCD1602 | |||||||||
| Interface | RS485/RS232/Wifi/LAN | |||||||||
