GROWATT Commercial & Industrial PV Inverter MAC 50-70KTL3-X LV/MV
SUPERIOR PERFORMANCE LFP BATTERY
All kinds of communication methods available
● ShineLink-X
● ShineWiFi-X/ShineLan-X/Shine4G-X
● ShineMaster
● SEM/SEM-D
Powerful free platforms for global customers
● 3 MPPTs
● Smart diagnosis
● High efficiency up to 98.8%
● OLED display and touch button
● AC&DC type II SPD
Smart Monitoring Platform
|
Datasheet |
MAC50KTL3-XLV |
MAC50KTL3-XMV |
MAC60KTL3-XLV |
MAC60KTL3-XMV |
MAC70KTL3-XMV |
|
Inputu Data(DC) |
|||||
|
Max. recommended PV power(for module STC) |
75000W |
75000W |
90000W |
90000W |
105000W |
|
Max.DC voltage |
1100V |
||||
|
Start voltage |
250V |
||||
|
Nominal voltage |
600V |
700V |
600V |
700V |
700V |
|
MPPT voltage range |
200V- 1000V |
||||
|
No. of MPP trackers |
3 |
||||
|
No. of PV strings per MPP tracker |
4/3/3 |
4/3/3 |
4/4/4 |
4/4/4 |
4/4/4 |
|
Max. input current per MPP tracker |
52A/39A/39A |
52A/39A/39A |
52A/52A/52A |
52A/52A/52A |
52A/52A/52A |
|
Max. short-circuit current per MPP tracker |
55A |
||||
|
Output Data(AC) |
|||||
|
Rated AC output power |
50000W |
50000W |
60000W |
60000W |
70000W |
|
Max. AC apparent power |
55500VA |
55500VA |
66600VA |
66600VA |
77700VA |
|
Nominal AC voltage (range*) |
230V/400V (340-440V) |
277V/480V (425-540V) |
230V/400V (340-440V) |
277V/480V (425-540V) |
277V/480V (425-540V) |
|
AC grid frequency (range*) |
50/60 Hz (45-55Hz/55-65 Hz) |
||||
|
Max. output current |
80.5A |
66.9A |
96.6A |
80.2A |
93.6A |
|
Adjustable power factor |
0.8leading ...0.8lagging |
||||
|
THDi |
<3% |
||||
|
AC grid connection type Efficiency |
3W+N+PE |
3W+N+PE |
3W+PE |
||
|
Max. efficiency |
98.8% |
||||
|
European efficiency |
98.5% |
||||
|
MPPT efficiency |
99.9% |
||||
|
Protection Devices |
|||||
|
DC reverse polarity protection |
Yes |
||||
|
DC switch |
Yes |
||||
|
AC/DC surge protection |
Type II / Type II |
||||
|
Insulation resistance monitoring |
Yes |
||||
|
AC short-circuit protection |
Yes |
||||
|
Ground fault monitoring |
Yes |
||||
|
Grid monitoring |
Yes |
||||
|
Anti-islanding protection |
Yes |
||||
|
Residual-current monitoring unit |
Yes |
||||
|
General Data |
|||||
|
Dimensions(W / H / D) |
680/508/281mm |
||||
|
Weight |
52kg |
||||
|
Operating temperature range |
–25°C ... +60°C |
||||
|
Nighttime power consumption |
<1W |
||||
|
Topology |
Transformerless |
||||
|
Cooling |
Smart air cooling |
||||
|
Protection degree |
IP65 |
||||
|
Relative humidity |
0~100% |
||||
|
Altitude |
4000m |
||||
|
DC connection |
H4/MC4(Optional) |
||||
|
AC connection |
Cable gland+OT terminal |
||||
|
Display |
OLED+LED/WIFI+APP |
||||
|
Interfaces: RS485 / USB /WiFi/ GPRS / RF |
Yes/Yes /Optional/Optional/Optional |
||||
|
Warranty: 5 years / 10 years |
Yes/Optional |
||||
|
CE, IEC62116, IEC61727, IEC60068, IEC61683, IEEE1547 |
|||||
Gon6specifi,ccountrygri,dsta ndard3., IEC60529, KSC8565
All specifications are subject to change without notice .
